automatic oil press machine

Author: Admin View: Post Time: 2016 / 11 / 23

Introduction of automatic oil press machine

Automatic oil press machine is to put raw material into the machine and you don’t have to do any other operation generally. The temperature of the machine is controlled automatically and filtered by vacuum pump so the oil yield rate is high.

Advantages of automatic oil press machine
Automatic oil press machine is with advanced design and stable performance. It operates easily and maintain simply. Compared with the old equipment, the common oil yield rate is 2% to 3% higher. The oil can be pressed 2-3 kilogram more than the old version. So we may say the economic profit is enormous in the whole year.

Working principle of automatic oil press machine
The main part of sunflower seeds oil machine is the chamber, which is composed of cage and screw with the cage. Its working process is the reduce the space of spiral screw lead screw diameter or increase the space of circle diameter gradually, so that squeeze the chamber volume is shrinking. The seeds cake can be squeezed and sent out from the end part. Generally the whole process has three sections that is preparation, pressing and cake-out.

Technical parameter of automatic oil press machine

Type 6YL-60 6YL-70 6YL-80 6YL-100 6YL-120 6YL-150

Screw diameter  (mm)

 55 65 80 100 120 150

Screw speed (r/min)

 52 48 63 43 36 33-42

Power (main frame) (KW)

 2.2 3 5.5 7.5 11 15

Vacuum power (KW)

 0.55 0.75 0.55 0.75 0.75 4

Heater (KW)

 0.9  1.8  3 3.5 4 4.5

Handling capacity (kg/h)

 30-60  50-80 80-150 150-250 250-350 300-450

Weight (kg)

 220 280 500 850 1300 1950
Size (mm)  1200x780x1100 1400x860x1260 1650x1500x1700 1700x1600x1750 1800x1700x1750 2380x1850x2000

Oil yield table(FYR)

Oil press rate(%) Cookie thickness(mm) residual oil rate(%)
Sesame 42-55 1.0-1.5 <=7
Peanut 40-50 0.8-2.0 <=8
Rapeseed 28-38 1.0-1.5 <=8
Oil sunflower 28-35 1.2-1.5 <=8
Soybean 10-16 0.8-1.5 <=7
Flax 33-40 0.8-1.5 <=7
Cotton seed 11-25 1.0-2.0 <=6
walnut 42-52 0.8-1.5 <=6
Camellia seed 26-38 1.0-2.0 <=6

Factory workshop photo

automatic oil press machine

Packing & delivery photos

automatic oil press machine

automatic oil press machine
